Huawei eKit AX3000 Dual Band Gigabit Wi-Fi 6 Access Point (AP362E) 3 Year Official Warranty - On Installments - IS-0217

Technical specifications

Dimensions (diameter x length)

Φ180 mm x 35 mm

Weight

0.45 kg

Port type

1 x 10M/100M/GE electrical port

The GE electrical port supports PoE IN.

LED indicator

Indicates the power-on, startup, running, alarm, and fault states of the system.

Power specifications

Power input

PoE power supply: in compliance with IEEE 802.3af

Maximum power consumption

9.4 W

The actual maximum power consumption depends on local laws and regulations.

Environmental specifications

Operating temperature

0°C to 40°C (From 1800 m to 5000 m, the maximum temperature of the device decreases by 1°C for every 300 m increase in altitude.)

Storage temperature

–40°C to +70°C

Operating humidity

5% to 95% (non-condensing)

Altitude

–60 m to +5000 m

Atmospheric pressure

53 kPa to 106 kPa

Radio Specifications

Antenna type

Built-in smart antennas

Antenna gain

2.4 GHz: 4 dBi 5 GHz: 5 dBi

1. The preceding gain is the peak gain of a single antenna. 2. Equivalent antenna gain after all

2.4 GHz or 5 GHz antennas are combined: 2 dBi for 2.4 GHz and 3 dBi for 5 GHz.

Maximum quantity of SSIDs

16

Maximum number of access STAs

128

The actual number of users varies according to the environment.

Maximum transmit power

2.4 GHz: 23 dBm (combined power) 5 GHz: 23 dBm (combined power)

The actual transmit power depends on local laws and regulations.

Power adjustment increment

1 dBm
