| Parameter
Type (Y11d) | Parameter name | Contents |
| Basic product information | Brand | vivo |
| Product series | Y
Series |
| Phone type | 4G
smartphone |
| Front CCM | Front
main camera |
| Rear CCM | Rear
main camera;Rear auxiliary camera |
| IP (Ingress Protection) Rating | IP65 |
| Display | Main
display |
| Middle
frame material | Plastic |
| Battery cover material | Plastic
composite sheet |
| Back cover process | Plastic
composite sheet |
| Side button material | Plastic |
| Earphone port | 3.5
mm American standard |
| Camera flash | Rear
flash supported |
| Type of fingerprint sensor | Side-mounted
capacitive fingerprint sensor |
| Material of camera lens | Glass |
| Camera flash type | Single
rear flash with single color temperature |
| Fill light | Not
supported |
| CPU/GPU | Material
code | 0800327 |
| Memory | RAM
capacity | 6
GB |
| ROM capacity | 128
GB |
| RAM type | LPDDR4X |
| Number of RAM channels | Dual
channel |
| RAM and ROM integrated or not | False |
| ROM type | eMMC
5.1 |
| Expandable RAM capacity | 6
GB |
| Expandable ROM capacity | 2
TB |
| Main display | Material
code | 1212030 |
| Display material | LCD |
| Front main camera (hardware) | Material
code | 2371754 |
| Focus type | FF |
| Smart
HDR | Supported |
| Video recording resolution | 1080P;720P |
| Rear main camera(hardware part) | Material
code | 2371714 |
| Focus type | AF |
| Phase focus | Yes |
| Rear auxiliary camera(hardware part) | Material
code | 2371756 |
| Focus type | FF |
| Smart
HDR | Supported |
| Video recording resolution | 1080P;720P |
| Maximum
wired charging power | 44W |
| Number of battery cells | Single
cell |
| QC protocol supported by wired charging | 9V/1.6A
(plug-in charger) |
| PD protocol supported by wired charging | PD3.0
PPS (5-11V 4A Max) |
| The charging solution is compatible with fast
charging protocols and power | Vivo
Flash Charge | 44W
Flash Charge (supports maximum input charging specifications of 11V 4A),
compatible with 33W (11V 3A), 22.5W (10V 2.25A) |
| UFCS fusion fast charging | Does
not support |
| PD3.0 protocol (PPS fast charging) | 44W
(11V 4A) |
| PD2.0 protocol fast charging | 15W
(9V 1.6A) |
| HVDCP 9V fast charging | 15W
(9V 1.6A) |
| Standard charging | 10W
(5V 2A) |
| 4G
network | TD-LTE;FDD-LTE |
| 3G network | WCDMA |
| 2G network | GSM |
| LTE MIMO (2×2) | (B1?B3?B5?B8?B40)(ID)?(B1?B3?B5?B7?B8?B20?B28?B38?B40?B41)(PSA?MY?KE?MEA-A?AF?MEA-C?BD?LK?PK) |
| WCDMA diversity | B1;B5;B8 |
| Carrier Aggregation (CA) support | Supported(ID)?Not
supported(PSA?MY?KE?MEA-A?AF?MEA-C?BD?LK?PK) |
| VoLTE | Supported |
| ViLTE | Supported |
| HD Voice | Supported |
| VoWiFi | Supported |
| DLNA | Supported |
| Support A2DP or not | Supported |
| SIM card | SIM
card type | 2
nano SIMs + 1 microSD |
| SIM1 type | Nano
SIM |
| SIM2 type | Nano
SIM |
| Dual SIM mode | Dual
SIM Dual Standby |
| Dual SIM network | L
+ L |
| Supported SD card types | MicroSD |
| Data connection | OTG | Supported |
| Reverse charging | Supported |
| Type of USB protocol | USB
2.0 |
| USB port | Type-C |
| FM | Supported |
| Bluetooth protocol | 5.2 |
| Bluetooth audio specification | SBC;AAC;aptX;aptX
HD;LDAC |
| Wireless AP/WLAN hotspot | Supported |
| EAP SIM | Supported |
| Bluetooth feature | Single
antenna (SISO) |
| WLAN frequency band | 2.4G;5G |
| WLAN protocol | 802.11b/g/n;802.11a;802.11ac |
| WLAN feature | Wi-Fi
Display;MU-MIMO |
| GPS | L1 |
| BeiDou | B1C |
| GLONASS | G1 |
| Galileo | E1 |
| QZSS | L1 |
| GNSS feature | AGPS;
Cellular network positioning; Wireless local area network positioning |
| Support listening to broadcast via speaker or
not | Supported |
| Keyboard type | Virtual
keyboard |
| Data transmission interface | Wi-Fi
hotspot; Bluetooth; OTG interface |
| Common features | Eye
protection mode; Notes; Calculator; Local video editing; Recorder; Screen
recording |
| WLAN bandwidth (2.4G) | 40
MHz |
| WLAN bandwidth (5G) | 80
MHz |
| Maximum rate of WLAN (2.4G) | 200
Mbps |
| Maximum rate of WLAN (5G) | 433
Mbps |
| Supported
wired standards and protocols | USB-OTG;USB
reverse charging |
| WLAN hardware parameter | 2.4G
(SISO);5G(SISO) |
| Sensor | Accelerometer | Supported |
| Ambient light sensor | Supported |
| Proximity sensor | Supported |
| E-compass | Supported |
| Fingerprint sensor | Side-mounted
capacitive fingerprint sensor |
| Motor | Ordinary |
| vivoCloud | Supported |
| Breathing light | Support |
| Mic noise reduction | Single-mic
noise reduction |
| Audio
recording | Supported |
| Video playback format | MP4;3GP;AVI;FLV;MKV;WEBM;TS;ASF |
| Other special features | Smart
motion | Supported |
| Smart on/off display | Supported |
| Smart call | Supported |
| Two-way call recording | Not
supported(PSA?AF)?Supported(PSA?ID?MY?KE?MEA-A?MEA-C?BD?PK?LK) |
| Super screenshot | Supported |
| WeChat key | Supported |
| Face Access | Supported |
| Accessories | Accessories
info (Industrial design) | Phone;
Eject tool; Warranty card; Quick start guide |
| Accessories info (Structure) | Phone
case |
| Accessories info (Electronics) | Charger;USB
cable |
